Binnops builds Smart Digital Twins for existing and operating Industrial Assets to improve operational efficiency, reduce the O&M Cost and mitigate Assets risks.

We build the 3D Models of a Facility using Reverse engineering Techniques and then Link its virtual elements with its real time components in the field.

Big data collected from the operation is processed to generate rich and valuable information.

At Binnops we are experts at producing intelligent Digital Twins that address the needs of Engineering, Operations, Maintenance and Asset Management.

The technology, from laser scanning to Internet of Things and Management of Change, is mature, functional, cost-effective and proven. Using Digital Twins with centralized Engineering and Operations data For plant operations and asset management, is the “next big thing”.

Binnops have developed more than 50 projects for International Clients that generates lower operational costs, efficiency improvement and better reliability .

Binnops IT Architecture — involving 3D virtual models of any type of Asset - is transforming the way we work, replacing 2D abstract representations such as layouts, isometric drawings, P&ID’s etc, with virtual elements. This is the most advanced way to implement a real Digital Transformation Process.

Asset Visualization

Smart Digital Twins

Smart Data Management

× Back to services

Asset Visualization

Save money and improve decisions by walking virtually over your asset and its real As Built Condition. Binnops offers a walk-through platform to visualize your asset via Internet.View more

Terrestrial Laser Scanning

The path to an “as-built” 3D virtual model of plant facilities and assets is surprisingly easy. If a 3D design model does not already exist, Laser Scanning technology and or other techniques are used to collect field information.. View more

Aerial Scanning with Drones

Ground Scanning of extended areas can be surveyed by using Lidar and other optical instruments mounted over Drones to produce point cloud data. Collected data gets processed to generate terrain geographical conditions, ground contour lines, mapping, and 3D Terrain Digital Models.View more

Asset Visualization

Digital Twins exploits the human visual system to provide an intuitive, immediate and language-independent way to view and show data. It is an essential tool for understanding information. View more

× Back to services

Smart Digital Twins

Binnops develops and Implement the foundation of your Digital Transformation by building 3D Intelligent Digital Twins that permits advanced visualization of Engineering, Revamps , Maintenance, Reliability and Plant Operations , for any type of Asset. View more

The Digital Hub

After capturing field data via the laser scanning techniques, the next step includes the conversion of the Geometrical As built Model into an Intelligent Model by adding and identifying tags and other asset information. By tagging objects, components, structures, circuits and subsystems, the model shapes gain context and can be used for searching, sorting, and linking to relevant data from all other plant information systems. The result is an asset management environment that we call “asset virtualization.”View more

Digital Hub Applications

× Back to services

Smart Data Management

One key breakthrough in the industrial world is Data analytics capabilities generated on existing platforms and different applications for many knowledge domains. View more

Internet of things (IoT)

At any Asset level (Location, process or even individual sensors or instruments) and connected to any Database from available applications (Processes, operations, maintenance, etc.), Data can be transferred and structured directly into cloud IoT solutions and provide the Binnops digital hub with flexible Dashboards.View more

Robotized Process Automation ( RPA )

The Binnops digital hub integrates Robotized Process Automation (RPA) services to deal with great quantities of activities that require to be performed repeatedly within limited lengths of time. Many use cases related to rapid Data documentation, required reports, and key performance indicators’ calculation are typical prospects..View more

Data Analytics

The Binnops digital hub is able to evolve the Data analytics required by customers going from very basics to the most advanced levels. Despite the progress in the analytics scale (Descriptive, Diagnostic, Predictive and Prescriptive) depends on organizational culture, existing personnel capabilities and level of maturity of Data infrastructure, we propose a Road Map that pushes analytics capabilities’ implementation at a proper pace. View more

Artificial Intelligence : ( AI )

From a Diagnostic analytics level on, the Binnops digital hub integrates Machine and Deep Learning capabilities to implement preventive, predictive and prescriptive analytics’ routines on critical systems, processes or assets. In such cases, when critical variables must be automatically monitored, controlled and even corrected, we work along with customers to set proper levels of alarming and communications strategies to make sure that correction View more

Cibersecurity

People are the first and last line of cyber security defense. While you will never stop all cyber-attacks, a digital twin can be effectively applied as a training simulator and in testing to move to a more proactive and predictive approach to detecting cyber compromisesView more

Business Model

Value Proposition. Our Digital Hub introduces a fundamental and significant change (a breakthrough) in the way people perform work. Because the industry workforce is aging, the capture, documentation and transfer of their know-how using asset virtualization is essential. Future plant workers will greatly benefit from this knowledge and thrive in a more modern 3D virtual model environment. View more

Plant owners and operators also must consider that environ- mental issues and corporate responsibility are in the governmental spotlight. Regulations requires internal awareness and proper controls over information and processes that relate to the business’s financial health, including asset documentation. Corporate Governance draws attention to leadership’s role in making safety in industrial processes and equipment “a core value” of any company. OSHA 1910 calls on companies to meet standards of safety for workers and the local environment. Binnops Digital Process facilitate these efforts in important arenas while delivering the operational excellence that distinguishes world-class companies.

By projects

Binnops Offers the individual activities associated to Laser Scanning, Models Production, Data Capture and Analysis on a Project Basis under a Lump Sum Price and based on a detailed scope of work. Individual services will include Field Data Capturing, Engineering data Updating ; 3D model Production ; IoT & Data Analytics.
By Data as a Service

Binnops also offers a modern business option by selling Data as a Service. Asset Visualization and Digital Twins can be enjoyed by accessing the Data via web while paying a recurrent fee per month.

Our Digital Transformation Road Map

Data Capture

Digital Twin

Real Time Data Capture

Data Analytics

Artificial Intelligence

Data Capture

Digital Twin

Real Time Data Input

Data Analytics

Artificial Intelligence

Experience

Binnops have executed over 100 Laser Scanning projects and produced more than 75 3D Intelligent Models ( Digital Twins ) , including the updating of engineering information, the capturing of static and dynamic data from sensors, PLC’s or data bases and the production of dashboards with rich and intelligent data linked to the asset components. View more

Binnops owns its own sets of laser equipment, lidar equipment, drones, and software platforms that allows the efficient production of rich data using reverse engineering techniques and required to improve efficiency in Assets Management. Binnops employs over 50 engineers, designers, technicians and data science engineers to implement digital transformation process in Industrial and Commercial Assets.

Barrancabermeja, Colombia

Refinery Process Plant

Laser Scanning and construction of a Digital Twin for all the structural Steel, Process piping, Instruments, and mechanical equipment of the entire UOP I unit of the Ecopetrol Refinery in Barrancabermeja, Colombia

Alberta, Canada

Steam Generation Plant.

Point cloud processing, data registration, generation of geometric models, updating of 750 P&ID's, production of Intelligent P & ID's plans in as built condition, database construction, intelligent model construction on Bentley AutoPlant platform and generation of 6,000 isometrics for eight plants and their well pad systems at Suncor's Vapor Injection complex in Canada.

Bogotá, Colombia

Government Building

Laser Scanning, data Cleaning and Data Registration of a 50,000 square meter complex Complex of Consular Services units and the Embassy of United States

Barrancabermeja, Colombia

Process Plant

Laser Scanning and construction of a Digital Twin for all the structural Steel, Process piping, Instruments, and mechanical equipment of the UOP II unit of the Ecopetol Refinery in Barrancabermeja, Colombia.

Cartagena, Colombia.

Crude Unit Process

Laser Scanning and construction of a Digital Twin in Hexagon Smart Plant 3D (SP3D) for all the structural Steel, Process piping, Instruments, and mechanical equipment of the Crude Unit located in the Reficar Refinery in Cartagena, Colombia.

Cartagena, Colombia.

Process Pipe Racks

Laser Scanning and construction of a Digital Twin for +3 km of 4-levels Pipe Racks of units of the Cartagena Refinery in Colombia.

Angola, Africa

OffShore Platform

Cloud Point Data Processing, data registration, geometrical model generation, Updating of P & ID’s of a Offshore plant gas processing located in the Angola Sea in Africa

Puerto Gaitan, Colombia

Separation Facility and CPF

Laser Scanning, Underground Scanning, Cloud Point Data Processing, data registration, 450 P&ID’s Updating and geometrical model generation on Aveva PDMS software for Separation Plant in the Eastern plains of Colombia.

Cajicá, Colombia.

Chemical Process Plant

Laser Scanning , Underground Scanning and Digital Twins of Process Pipes and Mechanical equipment for a Chemical Process Plant located in Cajicá, Colombia.

Scanning of a distribution and Pumping Systems as well as georeferencing of components and equipment through using Lidar mounted over a drone.

Houston, Texas

Pipe Racks Geometrical Modeling

Cloud Point Data Processing, data registration, geometrical model generation for 55 Km of Process Pipe racks in 5 levels for a petroleum refinery located in Texas. U.S.

Cartagena Refinery

Industrial Services and Steam Generation Plant.

Laser Scanning and construction of a Digital Twin in SP3D for all the structural Steel, Process piping, Instruments, and mechanical equipment of the Industrial Services Complex located in the Reficar Refinery in Cartagena, Colombia.
